Specifications

Type

Front-firing active driver, down-firing passive

Active Driver Size & Material

10 in. FibreAlloy™, 254mm long-throw, inverted alloy dust cap, steel chassis

Passive Radiator Size & Material

10 in., 254mm long throw, inverted dust cap

Low Frequency Extension

-6dB at 27 Hz

Input Connectors

High Level Neutrik Speakon, Low Level single RCA, LFE RCA

Output Connectors

N/A

Power Output

300 watts (RMS)

Amplifier Type

Class A/B

Wireless Capability

Arrow (Optional), Zero Compression Single Large Scale Integrated Chip

Dual Parametric Filter

N/A

Protection System

Fully Electronic Set Safe

Yes

D.C. Fault

Yes

Output Short

Yes

Mains Input Voltage

220-240 volts, 110-120 volts for certain markets

Fuses

3.15 Amp semi delay 230 volts operation, 6.3 Amp semi delay 115 volts operation

Dimensions

W x H x D

14.5 x 13.4 x 15.5 in., (370 x 340 x 393 mm)

Net Weight

45.5 lbs. (20.6 kg)

Finish

High Gloss Black, High Gloss White, 5 coats

Supplied Accessories

Mains Lead

Yes

Neutrik Speakon

Yes (10 Meters Nominal)

Interconnect

Users Manual

Yes

‍
