•PREAMPLIFIER (measured at XLR output)
•Maximum Output (<0.1% THD) 10.7 VRMS, Subwoofer 11 VRMS
•Frequency Response 20 Hz — 35 kHz (+/-0.2dB)
•Frequency Response, Analog-Direct 20 Hz — 80 kHz (+0, -2 dB)
•THD+N (4 Vrms output) -100 dB
•S/N Ratio (4 Vrms output, IEC-A filter) 110 dB
•XLR Configuration Pin 1: Ground, Pin 2: Positive, Pin 3: Negative
•POWER CONSUMPTION
•Typical Load 60 W
•Standby 0.3 W
•Standby IP Control Enabled 1.8 W
•Standby HDMI Bypass Enabled 4.9 W
•DIMENSIONS
•Height (without feet) 6" (15.24 cm)
•Height with Rackmount Kit 4U
•Width 17" (43.18 cm)
•Depth (including wifi ant not power cord) 14-1/2" (36.4 cm)
•Weight 22.1 lbs, 10.1 Kg
